MOLYBDENUM DISULFIDE
Mmolybdenum disulfide is a lubricant grade of molybdenum disulfide(MoS₂) available in three grades_­­­­–Technical,Technical Fechnical Fine,and Super Fine.Typical MoS₂ content (calculated average)is 98.5%.


CHEMICAL SPECIFICATIONS
	Maximum	Maximum	Maximum
	% by wt	% by wt	% by wt
	Technical	Technical Fine	Super Fine
Acid Insoluble	0.50	0.50	0.50
Iron	0.25	0.25	0.25
Molybdenum Trioxide	0.10	0.10	0.15
Water	0.20	0.20	0.20
Oil	0.05	0.40	0.40
Carbon	0.50	0.50	0.50
Acid Number	0.05	0.50	3.0


*Acid number is determined at time of production. Prolonged storage will result in slight oxidation,which will produce an increase in acid number.The smaller particle size grades are more susceptible to surface oxidation.Acid number is expressed as an absolute value and is the mg of  KOH required to neutralize the acid in a one-gram sample.

PARTICLE SIZE SPECIFICATIONS BY Microtrac


Grade	D50	D99(Maximum)
Technical	16.0-30.0μm	180μm
Technical Fine	4.0-6.0μm	35.0μm
Super Fine	0.9-1.5μm	6.5μm


TYPICAL PARTICLE SIZE BY FISHER SUB-SIZER AND BULK DENSITY:


	Fisher Number,	Bulk Density
Grade	μm	(Scott)
Technical	3 to 4	1.3g/cm3
Technical Fine	0.65 to 0.80	0.4g/cm3
Super Fine	0.40 to 0.45	0.3g/cm3




PACKAGING


Grade	US Packaging Fiber Drum	Pallet weight
Technical	25kg	450kg
Technical Fine	25kg	450kg
Super Fine	25kg	450kg
	18 drums/pallet
